BREAKTHROUGH TECHNOLOGY
Discover the most efficient motor in the world.
AIR MOTOR^3 iS THE WORLD"S MOST ADVANCED MOTOR WITH THE SIMPLEST STRUCTURE AND MECHANICS. IT HAS THE LONGEST RANGE AND LOWEST CONSUMPTION
THE AIR MOTOR
AIR MOTOR^3 Using extremely advanced technology to decrease fuel consumption AIR MOTOR^3 able to provide more than 130 Kw (130 HP) consuming only 60 Liters/Min 1 MPa air.
Air Motor^3 easily replaces other type of power generators. It makes no reasonable use of wind, solar, nuclear, dam etc.
Air Motor^3 can heat, cool, drive your household machines. It can do in large scale. Very large scale.
LOW COST MANUFACTURING
AIR MOTOR^3 has the lowest part number and the easiest manufacturing procedures. It only uses common metal materials, depends on version it might be only built by steel.
ZERO EMISSIONS & EFFICIENCY
AIR MOTOR^3 consumes only air pressure, there is no emission! All the materials are fully recyclable. The highest efficiency in the world because the motor uses recompression, RPM independent fuel consumption, the power stroke effects for many revolutions, compensator to aid recompression, utilizes relative force shifting, longest range over 3000 KM, best energy conversion ratio!
AIR MOTOR SAFETY
AIR MOTOR^3 cannot catch fire it doesnt have anything that burns. The mechanical damage it might cause in accident is minimal because of the strong frame and low velocity power stroke etc.
AIR MOTOR^3 SCALABILITY
AIR MOTOR^3 cluster can serve as a power generto, water heater, cooler, etc for cities. MULTI LEVEL POWER ACCUMULATION can be used with this motor technology! MLPA greatly increases the efficency of power generating.
AIR MOTOR^3's FUTURE
AR MOTOR has geat development, scaleability and future. There is already a better version in development. AIR MOTOR^3 has at least a 100 years future.
AIR MOTOR^3 - TRUE GREEN TECHNOLOGY
AIR MOTOR is made of steel or some other metal or in special case a carbon fiber steel. They don't pollute or poison nature. They don't need to be washed off some burned materials. AIR MOTOR doesn't have anything in it that burns or have high frequency atomic/molecular interaction (like high ampere electricity or nuclear etc) It is totally safe to use, to manufacture, to live with! It is very important value of the AIR MOTOR^3 in the world that is totally green technology.
AIR MOTOR^3 - RELATIVE FORCE SHIFTING
AIR MOTOR relative force shifting means that a generated force has a pair and the side that does the work aka, runs the rotor is "shifted". This is achived by attacking the rings nearly ideally, tangentially and using the motion part or the resulting forces to drive the motor the force is shifted. The revolution part will be used to recompress. The force shifting is very important because without it there would be no torque. It is extremely useful becuase the input power will do less turn if the radius of the ring increases but more torque and power and less loss will in the flipping phase. It is one of the most important feature of the AIR MOTOR^3.
AIR MOTOR^3 - SMALL INPUT POWER
MOTOR^3 small input power means that the attack force will move relatively slowly. This also means that the input power and the outout power doesnt match, not even ideally. This is because the input power is in a relative frame aka on the rotor. The advantage of this that the input force doesnt have to run as fast as the rotor but can be as slow as 1/100 of the rotor's speed... So the input power is slow, the required power is less. This is fairly important value of the MOTOR^3 .
AIR MOTOR^3 - POWER STROKE EFFECTS FOR MANY REVOLUTION
MOTOR^3 because of the input power is relative and it is built on the rotor a power stroke is no longer - unlike in Internal Combustion cars - has to follow the rotor with the same speed with the same orientation etc. Its orientation relatively remains the same and 'velocity' usually significantly slower. Becasue the rings center is a axle that is receiving the torque force it is impossible to have velocity different than the rotor's however the force velocity is different because it is turning the ring... So this effect allows that one power stroke can actually last for many revolutions. 50 revolution/power stroke easily possible... Not need to tell how much it lowers thet fuel consumption... Its extremely important value of the MOTOR^3 .
AIR MOTOR^3 - RPM INDEPENDENT FUEL CONSUMPTION
AIR MOTOR^3's fuel consumption is RPM independent because the relative system is not really influenced by the RPM. The power stroke the flip ring wont be slower or faster becuase of the RPM and they wont need more fuel because of the RPM. Naturally there is an increasing friction that has to be dealt with but generally speaking AIR MOTOR doesnt need more fuel at higher RPM unlike internal combustion engines or electrical motors. It is a natural phenomena of the AIR MOTOR. Of cource this can be changed to go over the linear power/rpm behaviour of the motor.
AIR MOTOR^3 - RECOMPRESS GENERATES FULL POWER STROKE
AIR MOTOR^3's recompress phase when the rolling ring is flipped generates full power stroke. This means that the stored kinetic energy of the revolution of the ring can be used to generate power. After the 1st power stroke the ring revolves the opposite direction to the rotors revolution. This direction has to be flipped so the ring is flipped. Thus now the rings rolling direction is the same as the rotor's. SO the kinetic energy of the rolling can be used as recompressing energy that the compressing piston chamber is going to consume. But while it consumes the ring again wants to roll away but the axle at the center hold the ring and this generates full power stroke. BTW there is some loss and that loss is compensated by a compensator. So the compensator is aiding the rolling and the flipping speed to match it to the required speed to be able to recompress to the necessary pressure.
AIR MOTOR^3 - LONGEST RANGE 3000 KM+
AIR MOTOR^3 has equipped with load of technology and features allows it to sincerely beat the competition down into the dust. It easily drives a 2.2 tonn car with velocity over 100 Km/h to 3000 Km+ distance! Its nothing for it. A compressor built into the car supports the AIR MOTOR, after 3000 Km it maybe needs to stop for some water and so. No other car motor can do this in the world!
AIR MOTOR^3 - BEST ENERGY CONVERSION
AIR MOTOR^3 has the best energy conversion ratio. The compressor that delivers the pressure to the tank utilizes only a couple of Kilo Watts to support the motor. This pressure then delivered to the rotor's tube axle and from this to the compensators. The consumption really only depends on the frequency of the compensators, impulse aka power stroke. So the compressor uses only a few Kilo Watts to produce the compressed air for the AIR MOTOR^3 and the motor is able to produce a couple of 100 Kilo Watts of mechanical power. Since relative systems is brand new the conversion rate might feel a scam because it is is huge like 1:100 or so. But if you look at nuclear powered engines, or IC engines this is not uncommon at all. To produce a liter petrol based benzine not need to use 150 kilo watts mechanical power for 10 minutes, only some, with turbo etc these rates of their climb up to 1:15 or so. Here you are a new system that is green and has the greatest energy conversion/utilization ratio.
AIR MOTOR^3 SOLVER
The torque and power curve of the cylinders can be combined to a much better curve that is achieved by "phase shifting".
